China Small Corn Flakes Making Machine and Production Line for Sale
CE Certified
ISO Certified
60+ Countries

China Small Corn Flakes Making Machine and Production Line for Sale

Automatic breakfast cereal food making machine for corn flake Product Description Industry Breakfast Cereal Crunchy Corn Flakes Machine. This corn flakes processing line takes corn and other cereals as main material. consists of mixing. extruding. pressing. drying and coating. which can be finished in one time. characterized by high efficiency. fully automatic. The final products […]

High Efficiency
Customizable
PLC Control
After-Sales Support

Product Description

Automatic breakfast cereal food making machine for corn flake
Product Description

Industry Breakfast Cereal Crunchy Corn Flakes Machine.

This corn flakes processing line takes corn and other cereals as main material. consists of mixing. extruding. pressing. drying and coating. which can be finished in one time. characterized by high efficiency. fully automatic.
The final products can be natural corn flakes. sugar-coated corn flakes. and breakfast cereals with different shapes.
Basic material
powder of Corn. rice. wheat. oat. barley. etc.
Production procedure
Mixing. Extruding. Flaking. Roasting. High temperature inflating. sugar-coating. Roasting. cooling. packing.
Final Products
Natural corn flakes; Coated corn flakes; Variety shapes of breakfast cereals are available. such as ball. tube. stick. ring. fruit loop. star. wheel and flower and heart shape by adjusting the mould in the extruder.
Capacity
100-500kg/hr with different model machines
Processing Flow
Our engineer could design the layout drawing according to your factory size. Customization is accepted.

Natural Corn flakes production line.

Mixing–Extruding–Flaking–Drying–Hot Air roasting–Cooling–Packing

Sugar Coated Corn Flakes Production Line.

Mixing–Extruding–Flaking–Drying–Hot air roasting–Sugar spraying–Sugar Coating–Drying–Cooling–Packing

Technical Parameter
Model
Installed power
Power consumption
Capacity
Size
MT70
160KW
120KW
150-200KG/HR
41 x 1.5 x 2.2m
MT85
190KW
140KW
300-400KG/HR
43 x 1.5 x3.2m
MT75
210KW
150KW
300-500KG/HR
45 x 1.5 x3.5m
Sample Picture
Corn flakes with/without sugar.
With some machines of this corn flakes processing line. various shapes of breakfast cereal snacks can be produced also.
Machine Details
Name
MT-75 Twin Screw Extruder
Capacity
200-300kg/hr
Usage
puffing snacks extrusion
Working principle
Consists of feeding system. extruding system. cutting system. heating system. gearing system and controlling system.
Advantage
Automatic lubricating. cooling function. guarantee safe running.
Screw is made by special tech. bear grinding. steady and reliable. long service life.
Name
Corn Flakes Dryer Machine
Heating Source
Gas. Electric
Capacity
According to Extruder
Function
drying puffed snacks after extruding. pre-drying snacks. to avoid sticky problem for next procedure.
Name
New type Corn flakes flaking machinery
Capacity
200-300kg/hr
Usage
Flaking the puffed corn granules into flakes
Advantage
PLC control system;
Hydraulic system for double rollers;
Double Motors for separate roller driving;
temperature pipe is controlled evenly by
infrared sensor.
Name
Hot air roasting oven
Function
after hot air roasting. bubbles will happen on the surface of corn flakes. then crispy
 corn flakes will be produced.
Consists
vibrating pan with high temperature spraying tubes.
The combustion chamer adopts conciliation burner.
Two separate circulating fans and cyclone dust removal device.
Advantage
sanitary.
precise temperature control
Name
Coating system
Consists
double tumble for sugar melting. elevator.
coating drum. spraying nozzle.
Function
melting and spraying sugar onto the surface of natural corn flakes.
Capacity
According to Extruder. different model will be chosen.
why choose us
Specializing in R&D. production. sales. application promotion of food engineering projects.With more than 10 years of quality. expertise and professionalism on puffed snacks machine industry. we have gained good reputation on market.
We offer one-turnkey solution project for customers. Machine customized is accepted according to customer's requirements. With high quality machines . cost-effective price and good after-sale service. our machines have been popular on market. welcome you to visit us before ordering.
Until now. our machines have been exported to many countries. which gains good reputation from all over the world.
Packing&Delivery
Plastic bubble film on the surface of machines. then wooden case for the spare parts of all processing line based on customer's requirements.
We can supply fumigation package and certificate.
Special packing requirement is available.
FAQ
1.Q: Are you manufacturer?
A: We are professional manufacturer for more than 10 years experience. with professional engineering and after-sales team.
2. Q: Do you offer formula?
A: we will supply basic recipe and machine setting parameters to customers.
3. Do you accept machine customization?
A: We will offer suitable proposal and factory layout according to customers' factory size and local voltage.
4. Q: what's your after-sale service?
A: After shipment. one or two engineers will be asked to your factory for machine installation. testing and training service.

15+
Years Experience
60+
Countries Served
1000+
Projects Delivered
24/7
Technical Support
